219~965mm OD Seamless Steel Tubing / Seamless Mechanical Tubing DIN 17175 3CrMo44 1

Name: 219965mm OD Seamless Steel Tubing Seamless Mechanical Tubing DIN 17175 3CrMo44 1
Brand: Y & G
Price: 1 USD

Quality 219~965mm OD Seamless Steel Tubing / Seamless Mechanical Tubing DIN 17175 3CrMo44 1 wholesale

Brand Name : Y & G

MOQ : Negotiation

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 8000MT/Month

Delivery Time : 25-35 days

Packaging Details : Exporting package/wooden box / per customers’ requirement

Material : 15Mo3, 13CrMo44, 10CrMo910

Standard : DIN 17175

Type : Seamless

OD : 219~965mm

Wall Thickness : 6~60mm

Application : Heat resisting Tube

Mark : As requirement

Contact Now

Seamless Steel Tubing DIN 17175 3CrMo44 1Heat resisting Tube

Standard: DIN17175

Main steel grades: 15Mo3, 13CrMo44, 10CrMo910

Application: For high-pressure boilers(working pressure is generally 9.8 Mpa above, working temperature is between 450 °C and 650 °C) hot surface pipes, coal economizers, superheaters, reheaters, petrochemical industry etc.

Chemical Requirements & Mechanical Proterties:

Grade	C	Si	Mn	P	S	Cr	Mo
15Mo3	0.12-0.20	0.10-0.35	0.40-0.80	≤0.035	≤0.035	/	0.25-0.35
13CrMo44	0.10-0.18	0.10-0.35	0.40-0.70	≤0.035	≤0.035	0.70-1.10	0.46-0.65
10CrMo910	0.08-0.15	≤0.50	0.40-0.70	≤0.035	≤0.035	0.20-0.25	0.90-1.20

Grade	Yield Strength (Mpa)	Tensile Strength (Mpa)	Elongation(%)
15Mo3	≥275	450-600	20
13CrMo44	≥290	440-590	20
10CrMo910	≥280	450-600	18

Mark: As required.

Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.

Delivery status: Annealed, normalized, normalized+Tempered, etc.

End: plain end, beveled end, threaded

End protection: plastic caps

Outside coating: black painting, anti-corrosion oil,galvanized finish, finish as per customer requirements.

Packing: Exporting package/wooden box /as requirement.
